How to use our design tool

Our easy-to-use tool lets you select the style and shape of your truss, change the roof pitch, section sizes and lengths. The configurator will show you the shape live as you make changes and only allow values that are structurally sound, depending on the length of your tie beam.

The tool offers three basic truss styles for you to adapt.
For more guidance, follow our step-by-step guide below.

Looking for more information about truss styles and bespoke options?

Bespoke designs

King post truss

A classic, triangle shape with a straight vertical post coming from the middle of the tie beam, with diagonal or vertical struts.

Fluted King Post Truss

The same classic shape, but with additional detailing to the central post giving it a fluted, or flaired shape. The braces can be curved and offset, or straight.

Queen Post Truss

Two vertical posts and a collar form a square or rectangular shape inside the triangle. Queen Post trusses can be curved or angled without the collar beam and with curved vertical posts.

Step-by-Step...

Select the type of truss type you prefer - King Post, Fluted King Post or Queen Post.
Select the roof pitch, section options, lengths and sizes You can use the sliders, or type the values .
The tool offers a maximum span of 9 metres. However we are able to manufacture larger trusses on request. Need a bespoke size? Simply get in touch
You’ll receive an email with all the details. We will then review your design and contact you with a quotation.

Design your truss

What's included...

VAT
Supply ex works of the oak roof truss.
Complete installation instructions for your builder
Post-delivery advice over the phone or by email
Finish: planed all around

...What's not included

Roof tiles, bricks or concrete
Delivery (unless added to your order)
Hire of any lifting or site equipment
Installation or any building work
Planning drawings for the oak truss, unless specified
Structural calculations unless specified
